18x15W 6in1 Outdoor LED Pixel Bar
Model: LS-A004B-18x15W-6in1-Pixel-IP
Specification Overview
Optical System
- Light Source: 18x15W RGBWA + UV 6in1 LED(Pixel)
- Beam Angle: 22°~52°
Effect
- Single pixel control,dimmer,strobe,static color,color macro
Control & Display
- Control Channel: 11/29/108/119CH
- Control Protocol: standard DMX512, master-slave model, sound activated control, auto operation
- Menu Display: LCD display
Power Parameter
- Voltage: AC110-240V,50-60Hz
Working Environment
- Outdoor use
IP Rate
- IP 65
Others
- Color temperature correction
- Cooling: Convection
- DMX Connector: PG 3pin dmx in/out
- Power Connector: PG 3pin connector
- Housing Material: Die-cast aluminium
Dimension & Weight
- Fixture Dimension: L101x W9.5 x H17cm(including holder height)
- Package Dimension: 1110x30x160mm(1 set/carton)
- Gross Weight: 9.8kg/carton, 40kg/4sets/master carton
** Errors and omissions are possible. All specifications are subject to change without prior notice. **
