12x15W 6in1 Outdoor LED Bar
Model: LS-A004C-12x15W-6in1-IP
Specification Overview
Optical System
- Light Source: 12x15W or 14x15W 6in1 LED
- Beam Angle: 23°~45°
Effect
- Dimmer,strobe,static color,color macro
- Single Pixel control (optional)
Control & Display
- Control Channel: 6/9CH
- Control Protocol: standard DMX512, master-slave model, sound activated control, auto operation
- Menu Display: LED display
Power Parameter
- Voltage: AC110-240V,50-60Hz
Working Environment
- Outdoor use
IP Rate
- IP 65
Others
- Color temperature correction
- Cooling: Convection
- DMX Connector: PG 3pin dmx in/out (or XLR-3pin,XLR-5pin)
- Power Connector: PG 3pin connector ( or Powercon)
- Housing Material: Die-cast aluminium
Dimension & Weight
- Fixture Dimension: L101x W9.5 x H17cm(including holder height)
- Gross Weight: 9.8kg/carton, 40kg/4sets/master carton
** Errors and omissions are possible. All specifications are subject to change without prior notice. **
