Indoor LED Pixel Bar
Model: LS-A205-Pixel
Specification Overview
Optical System
- Main Light Source: 14x3W warm white LED
- Background Auxiliary Light Source: 84/56x0.5W RGB LED
Effect
- Strobe: 1-20 times/sec
- Camera without flicker technology, high frequency of 1200Hz
- Stitching effects
- Single pixel for main light source
Control & Display
- Control Chanel: 6/8/12/60CH
- Control Protocol: standard DMX512, master-slave model, sound activated control, auto operation
- Menu Display: LED display
Power Parameter
- Voltage: AC110-240V,50-60Hz
- Power: 84W
Working Environment
- Indoor use
IP Rate
- IP 20
Others
- Power Connector: Powercon
- DMX Connector: 3 pin XLR
Dimension & Weight
- Fixture Dimension: 111x18x23cm
- Net Weight: 3kg
** Errors and omissions are possible. All specifications are subject to change without prior notice. **
